60,000 BTU Single Zone Ductless Mini Split Outdoor Condenser
60,000 BTU Single Zone Ductless Mini Split Outdoor Condenser
Model: Blueridge BM60UYC
highlights
*NOTE: This product is not a complete system, it is only one component. A complete system requires an indoor air handler, outdoor condenser and connecting line set. Please view complete systems here.
Heat or Cool Any Space,
Simply and Affordably
Simply and Affordably
Surprisingly
Affordable
Affordable
Incredibly
Quiet
Quiet
Great
Reviews
Reviews
Easy to
Install
Install
What is a Blueridge Ductless System?
It's a better way to heat and cool any space without the need for ductwork. Includes an outdoor heat pump condenser and 1 to 5 indoor air handlers. It's inexpensive to own and operate, easier to install and whisper quiet.
Homeowners and contractors love Blueridge ductless mini-splits. If you own a home, you will want one.
Blueridge mini-splits are a high quality, energy efficient and inexpensive option for cooling and heating many types of spaces without ductwork.
Blueridge mini-splits compare favorably to well-known brands at a fraction of the price. They have the highest online product ratings of all mini-split brands. Their affordability, ease of installation, and high quality make them a favorite among contractors and homeowners.
Benefits
Quiet
Both the indoor and outdoor units operate so quietly you may not be aware they are running. You will just be aware that you are comfortable.
Affordable
The great value extends beyond the low purchase price of these units. You will be pleasantly surprised by how inexpensive they are to operate.
Efficient
Lower your utility bills with inverter technology, by using less electricity and no fossil fuels to accomplish your heating and cooling needs. This is intelligent equipment for a sustainable and comfortable lifestyle.
Versatility
Because there is no ductwork, this is a solution for all kinds of hard-to-fit applications. Any room or space can be transformed into a place for you and others to enjoy for years to come.
Simple Installation
If you're handy, you can accomplish 90% of the installation yourself by following the simple directions and watching our helpful video. Bring in a professional to finish the job and you're set.
Heat or Cool Any Type of Space:
Entire homes
Condos
Bonus rooms
Hotel rooms
Small businesses
Studios
Tiny homes
Coffee shops
Pool houses
Workshops
Offices
Man caves
Attics
Casitas
Retreat spaces
Sun rooms
Basements
Garages
Enclosed porches
Mother-in-law apartments
Many more applications
Videos
Blueridge Ductless Mini-Split AC Highlights
Blueridge Mini-Splits also Provide Heat!
Great customer reviews
Great Product!
Simon
Cleveland, GA
This is an outstanding product at a reasonable price.
Mike
Birmingham AL
Great mini-split system!
Marq
New Bern, NC
Installed easily and works very quietly.
Mike
Palm Desert, CA
Excellent! Works great.
Vic
Jefferson, GA
I would buy it again.
Jack
Johns Creek, GA
Installation
Step 1
Mount
Once you have received the product, mount the indoor and outdoor units to your desired resting location.
Step 2
Connect
Next, run the line sets, drain line, and electrical wires from the indoor unit(s) to the outdoor unit.
Step 3
Electrical
Run a 220 volt power circuit from your main breaker to the outdoor disconnect. Then run the electrical whip from the disconnect to the outdoor unit.
Step 4
Pro Start Up
We'll help you get an HVAC contractor who will pressure test the line sets, check for leaks, and release refrigerant. Click Here For Details
How to Install a Blueridge Ductless Mini-Split AC System
View installation manual for complete instructions
CEO and Founder
Andrew Arthurs
Alpine Home Air Products
Blueridge ductless mini-splits are exclusive to Alpine Home Air and are one of our most popular brands. These units are manufactured to our specifications by the largest, most reputable HVAC manufacturer in the world.
Our customers love them! We receive rave reviews because these products are solidly-engineered, thoroughly tested, reliable, and quiet. Our customers order Blueridge because of the incredible value and savings. Competing brands cost more for one reason: a long supply chain raising the price before the product hits your door. With Blueridge, we buy directly from the manufacturer and our customers save thousands of dollars. Long established throughout the rest of the world, mini-splits are quickly gaining popularity across America. The ease of installation, versatility, and savings cannot be matched. We know you will love our Blueridge mini-splits as much as we do. Please tell your friends and help us get the word out.
Blueridge BM60UYC
Standard Features
Convenient remote control enables unique temperatures to be set per zone.
High-efficiency inverter technology allows for even cooling and heating while reducing energy costs.
Gold fin condenser coil coating extends the life of your system by protecting it from corrosion.
Intelligent sleep function adjusts to your sleep pattern in order to maximize your comfort and reduce energy costs. User controls direct air flow.
Intelligent defrost reduces energy and defrost time by only defrosting when needed.
This System Includes*
60,000 BTU Single Zone Ductless Mini Split Outdoor Condenser
Specs
System Information
Zones
1
Factory Precharge
25 Feet
Single Vs. Multi-Zone
Single zone
Mini-Split Series
BM Standard
Product Type
U-Match
Component Type
Outdoor Unit
Refrigerant
R-410A
Efficiency
Coefficient of Performance (at 47 F)
3.16 COP
Energy Efficiency Ratio
9.8 EER
SEER
18.0 SEER
Heating Seasonal Performance Factor
9.1 HSPF
Performance
Ambient Temperature Range (Cooling)
122 / 5 °F
Ambient Temperature Range (Heating)
5 / 86 °F
Low Ambient Cooling
Yes
Base Heating Capacity
60000 BTU
Total Cooling Capacity
5 Ton(s)
Maximum Heating Capacity
60000 BTU
Base Cooling Capacity
54000 BTU
Compressor Type
Inverter
Cooling Tonnage
5 Tons
Sound Rating, Outdoor
65 Decibels
Electrical Information
Frequency
60 Hz
Voltage Phase
1
Minimum Ampacity
36 Amps
Maximum Overcurrent Protection (Breaker)
50 Amps
Voltage
208 / 230 Volts
Line Set Information
Maximum Line Length per Zone
213 Feet
Maximum Height Difference
98 Feet
Liquid Line Size (OD)
3/8 Inches
Suction Line Size (OD)
3/4 Inches
Line Set Connection Type
Flare
Product Dimensions
Width
37 12/25 Inches
Depth
16 17/50 Inches
Height
52 12/25 Inches
Outdoor Condenser Size, W x H x D
37.48 x 52.48 x 16.34 Inches
Product Weight
224.9 lbs
Outdoor Condenser Weight
224.9 Lbs
Footprint Mounting Holes (W x D)
25 x 15.9 Inches
Warranty
Compressor Warranty
7 Years
Parts Warranty
5 Years
Certifications
ENERGY STAR® Certified
No
Accessories
Enjoy free shipping on any accessories purchased with the Blueridge BM60UYC.
Air Conditioning System Protectors
DiversiTech CGB-AER
Coil Guard - Aerosol, Blue
$3299
Electrical Disconnect
Alpine AG-DCT
Safety Non-Fused Electrical Disconnect
$2199
Electrical Whips
Alpine AG-WHP10
1/2 x 48 Inches, #10 Gauge Electrical Whip
$2499
Mini-Split Components
Blueridge BM60MFCC
60,000 BTU Single Zone Floor/Ceiling Console Ductless Air Handler
$95000
Mini-Split System Accessories
Alpine MW4/125
125' Stranded Mini-Split Communication Wire - Non-Shielded (600 Volt)
$14999
Alpine MW4/025
25' Stranded Ductless Mini-Split Communication Wire - Non-Shielded (600 Volt)
$4999
Alpine MW4/250
250' Stranded Mini-Split Communication Wire - Non-Shielded (600 Volt)
$29999
Alpine MW4/035
35' Stranded Ductless Mini-Split Communication Wire - Non-Shielded (600 Volt)
$5999
Alpine MW4/050
50' Stranded Ductless Mini-Split Communication Wire - Non-Shielded (600 Volt)
$6999
Alpine MW4/065
65' Stranded Ductless Mini-Split Communication Wire - Non-Shielded (600 Volt)
$7999
Alpine MW2/125
125 Foot 18/2 Stranded Ductless Mini-Split Wire - Shielded (300 Volt)
$5999
Alpine MW2/025
25 Foot 18/2 Stranded Ductless Mini-Split Wire - Shielded (300 Volt)
$1499
Alpine MW2/035
35 Foot 18/2 Stranded Ductless Mini-Split Wire - Shielded (300 Volt)
$1999
Alpine MW2/050
50 Foot 18/2 Stranded Ductless Mini-Split Wire - Shielded (300 Volt)
$2499
Alpine MW2/065
65 Foot 18/2 Stranded Ductless Mini-Split Wire - Shielded (300 Volt)
$2999
Alpine AHMSA1
Adapter 5/16" x 1/4" for Ductless Mini-Split Systems
$1999
Blueridge BY-30
Adjustable Steel Wall Bracket for w/ 30 inch long arms Ductless Mini Splits, 660 lbs Capacity
$7999
DiversiTech 230-MB17CW
(2-Pack) 17" Mounting Blocks with End Caps for Ductless Mini-Split Air Conditioner and Heat Pump Condensers
$4300
Mersen STXH240S05
STXH240S05 Type 1 50kA 240/120V Split Phase Surge Protector
$9999
Refrigeration Technologies RT201B
Nylog Blue Gasket, Flare and Thread Sealant
$1199
Outdoor Line Set Covers
Blueridge BGG130
Blueridge Line Set Cover Kit BGG130
$7999
DiversiTech 230-CP4
Coupling for Diversitech 4" SpeediChannel™ Line Set Covers
$1399
DiversiTech 230-D4 1M
39" Long,Diversitech 4" SpeediChannel™ Line Set Cover
$3999
DiversiTech 230-DC4
End Cap for Diversitech 4" SpeediChannel™ Line Set Covers
$1399
DiversiTech 230-DCLIP-10
(10-Pack) SpeediClips™ for DiversiTech Line Set Covers
$1099
DiversiTech 230-DE4
End Fitting for Diversitech 4" SpeediChannel™ Line Set Covers
$1499
DiversiTech 230-EB4
90° Inside Elbow for Diversitech 4" SpeediChannel™ Line Set Covers
$2899
DiversiTech 230-EIN4
90° Outside Elbow for Diversitech 4" SpeediChannel™ Line Set Covers
$3199
DiversiTech 230-FB4
90° Flat Bend for Diversitech 4" SpeediChannel™ Line Set Covers
$2899
DiversiTech 230-FB454
45° Flat Bend for Diversitech 4" SpeediChannel™ Line Set Covers
$3199
DiversiTech 230-FJ4
Flex Joint for Diversitech 4" SpeediChannel™ Line Set Covers
$2599
DiversiTech 230-FR4
Flat Wall Escutcheon for Diversitech 4" SpeediChannel™ Line Set Covers
$1199
DiversiTech 230-LFB4
90° Long Bend for Diversitech 4" SpeediChannel™ Line Set Covers
$2899
DiversiTech 230-WC4
Wall Connection Piece for Diversitech 4" SpeediChannel™ Line Set Covers
$3199
DiversiTech 230-WR4
Non-Flat Wall Escutcheon for Diversitech 4" SpeediChannel™ Line Set Covers
$1199
Documents
- U Match Performance Chart(PDF, 1.20 MB)
- Blueridge U-Match Outdoor Unit Wiring Supplement (M)(PDF, 944 KB)
- Blueridge Ductless Mini-Split Warranty(PDF, 180 KB)
